CENTURY

550-500 SERIES

100mm Single Glazed System

A 100 mm (nominal) × 60 mm unitized panel, single glazed curtain wall system suitable for low and high rise applications, accommodating up to 10.38 mm glass.

Features

• Waterproofing characteristics based on pressure equalisation principles
• Internal glazed wet seal for improved weatherproofing required on all applications.
• Accommodates 5 to 10.38 mm glass (4 sided structurally glazed can accommodate thicker glass size)

Limitations

• Finish floor to finish floor spans not to exceed 3m and mullion spans are not to exceed 1.2m (guide only - dependent upon engineering outcomes). Stack joint positioning relative to slab level will dramatically affect structural capabilities of the system. Optimum position of stack joint is between 15% and 20% of overall span height, up from bracketed fixing point (generally at slab level).
• To comply with the appropriate design wind load requirements and glazing standards

551-500 SERIES

100mm Double Glazed System

Types

• 4 sided captive glazed only

Features

• Waterproofing characteristics based on pressure equalisation principles
• Internal glazed wet seal for improved weatherproofing required on high-rise applications

Limitations

• Finish floor to finish floor spans not to exceed 3m (guide only dependent, upon number of and position of transoms)
• Note: Stack joint positioning relative to slab level will dramatically affect structural capabilities of the system. Optimum position between 15% and 20% of overall span height up from fixing point.
• To comply with the appropriate design wind load requirements and glazing standard

650-500 SERIES

150mm Single Glazed System

A 150 mm (nominal) x 60 mm unitized panel curtain wall system suitable for low and high-rise applications.

Types

• Four (4) sided structurally (on-face) glazed with no expressed external aluminium
• Four (4) sided captive glazed
• Two (2) sided structurally (on-face) glazed with expressed mullions only
• Two (2) sided captive glazed with expressed transoms only
• 600 Pascal water penetration rated

Features

• Waterproofing characteristics based on pressure equalisation principles
• Internal glazed wet seal for improved weatherproofing required on high-rise applications
• Accommodates 5 mm - 10.38 mm glass (4 sided structurally glazed can accommodate thicker glass size)

651-500 SERIES

150mm Double Glazed System

A 150 mm (nominal) x 60 mm unitized panel curtain wall system suitable for low and high-rise applications.

Features

• Waterproofing characteristics based on pressure equalisation principles
• Internal glazed wet seal for improved weatherproofing required on high-rise applications
• Accommodates I.G. units to 27 mm

Limitations

• Finish floor to finish floor spans not to exceed 3.5m (guide only - dependent upon number of and position of transoms)
• Note: Stack joint positioning relative to slab level will dramatically affect structural capabilities of the system. Optimum position between 15% and 20% of overall span height up from fixing point

To comply with the appropriate design wind load requirements and glazing standards

750-500 SERIES

200mm Single Glazed System

A 200 mm (nominal) × 60 mm unitized panel curtain wall system suitable for low and high-rise applications.

Features

• Waterproofing characteristics based on pressure equalisation principles
• Internal glazed wet seal for improved weatherproofing required on high-rise applications
• Accommodates 5 mm – 10.38 mm glass (4 sided structurally glazed can accommodate thicker glass size)

Limitations

• Finish floor to finish floor spans not to exceed 4 m (guide only dependent upon number of and position of transoms).
• Note: Stack joint positioning relative to slab level will dramatically affect structural capabilities of the system. Optimum position between 15% and 20% of overall span height up from fixing point.

• To comply with the appropriate design wind load requirements and glazing standards

751-500 SERIES

200mm Double Glazed System

• Waterproofing characteristics based on pressure equalisation principles
• Internal glazed wet seal for improved weatherproofing required on high-rise applications
• Accommodates I.G. units up to 27 mm.

Limitations

• Finish floor to finish floor spans not to exceed 4 m (guide only dependent upon number of and position of transoms).
• Note: Stack joint positioning relative to slab level will dramatically affect structural capabilities of the system. Optimum position between 15% and 20% of overall span height up from fixing point.

• To comply with the appropriate design wind load requirements and glazing standards
